Productinformatie
-
-
- Expand Wi-Fi Network for Ultimate Performance
- Expanded 450Mbps on 2.4GHz + 1300Mbps on 5GHz totals 1750Mbps Wi-Fi speeds
- Three adjustable external antennas provide optimal Wi-Fi coverage and reliable connections
- Gigabit Ethernet port acts as a wireless adapter to connect a wired device to your network at gigabit speed
- Intelligent signal light helps to find the best location for optimal Wi-Fi coverage by showing the signal strength
- Works with any Wi-Fi router or wireless access point
-
HARDWARE FEATURES Plug Type EU, UK, US Standards and Protocols IEEE802.11ac, IEEE 802.11n, IEEE 802.11g, IEEE 802.11b Interface 1 * 10/100/1000M Ethernet Port (RJ45) Button RE (Range Extender) Button, Reset Button, LED Button, Power Button Dimensions (W X D X H) 6.4x 3.0 x 2.6 in. (163 x 76.4 x 66.5mm) Power Consumption 9W(max power consumption) Antenna 3* external WIRELESS FEATURES Frequency 2.4GHz & 5GHz(11ac) Signal Rate 5GHz:Up to 1300Mbps
2.4GHz:Up to 450MpbsReception Sensitivity 5GHz:
11a 6Mbps:-93dBm@10% PER
11a 54Mbps: -76dBm@10% PER
11ac HT20 mcs8: -68dBm@10% PER
11ac HT40 mcs9: -64dBm@10% PER
11ac HT80 mcs9: -61dBm@10% PER
2.4GHz
11g 54M: -77dBm@10% PER
11n HT20 mcs7: -73dBm@10% PER
11n HT40 mcs7: -70dBm@10% PERWireless Modes Range Extender Wireless Functions Wireless Statistic
Concurrent Mode boost both 2.4G/5G WiFi band
High Speed Mode for great speed for HD Gaming and video
Access Control
LED Control
Domain Login FunctionWireless Security 64/128-bit WEP
WPA-PSK / WPA2-PSKTransmission Power <20dBm(2.4GHz)
<23dBm(5GHz)OTHERS Certification CE, FCC, RoHS Package Contents AC1750 Wi-Fi Range Extender RE450
RJ-45 Ethernet Cable
Quick Installation GuideBox Dimensions (W X D X H) 7.9 x 4.9 x 3.4in. (202x 125 x 86mm) System Requirements Microsoft® Windows® 98SE, NT, 2000, XP, Vista or Windows 7, 8, Mac® OS, NetWare®, UNIX® or Linux. Environment Operating Temperature: 0°C~30°C (32°F~86°F)
Storage Temperature: -40°C~70°C (-40°F~158°F)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
Operating Temperature: 0°C~40°C (32°F~104°F)
Storage Temperature: -40°C~70°C (-40°F~158°F)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing -
Specificaties
Algemeen
Merk:
TP-Link
Model Nummer:
RE450
Aansluitingen
Aantal Ethernet LAN (RJ-45)-poorten:
1
Netwerk
Verbinding (ethernet):
10/100/1000
Verbinding (wireless):
- AC1750
- Dual-Band (2.5GHz/5GHz)
Uiterlijk
Kleur Product:
Wit
